Picture this: A typical innovation day at our company, where developers gather to explore, tinker, and push the boundaries of what’s possible. Our group decided to delve into the GitHub Actions Runner Controller, blending it with Terraform magic and the wonders of Kubernetes.
Quick Summary: Streamline GitHub Actions Self-Hosted Runner Deployment with Terraform.
Effortlessly set up and dynamically scale self-hosted runners using Kubernetes and the GitHub Actions Runner Controller. If you already have a Kubernetes cluster, make use of our Terraform modules for seamless hosting:
Runner Controller Module: GitHub Actions Runner Controller
GitHub Actions Runner Module: GitHub Actions Runner
Revolutionize your CI/CD workflows with simplicity and scalability.
The GitHub Actions Runner Controller
Learn about the functionality of the GitHub Actions Runner Controller in the docs.
The core concept is to employ a Kubernetes cluster to execute jobs on self-hosted runners in containers, moving away from virtual machines.
ARC, a K8s controller, facilitates the creation of self-hosted runners on your K8s cluster. With minimal commands, you can establish self-hosted runners capable of scaling based on demand. These runners, being ephemeral and container-based, allow for rapid and clean instantiation. Find out more at ARC Documentation.
Setting Up A Kubernetes Hosted Action Runner
Now, let’s get hands-on with our GitHub Actions Runner Controller exploration. No embellishments, just an unfiltered account of our journey:
Step 1: Getting Started with GitHub Docs
Our GitHub Actions journey commenced by following the straightforward docs on Installing ARC. With a valid GitHub PAT, the process can be broken down into the following snippet:
# install cert manager
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
--namespace cert-manager \
--create-namespace \
--version v1.13.3 \
--set installCRDs=true
# install actions runner controller
helm repo add actions-runner-controller https://actions-runner-controller.github.io/actions-runner-controller
helm install actions-runner-controller/actions-runner-controller \
--namespace actions-runner-system \
--create-namespace \
--set=authSecret.create=true \
--set=authSecret.github_token="***" \
--wait actions-runner-controller
A classic start – deploying the Helm chart of the GitHub Actions Runner Controller and a runner.
apiVersion: actions.summerwind.dev/v1alpha1
kind: RunnerDeployment
metadata:
name: first-runner
spec:
replicas: 1
template:
spec:
repository: m4s-b3n/playground
Simple, right? Well, the devil is in the details.
Step 2: Docker Socket Security Revelation
Our first “aha” moment struck when we realized the runner was casually mounting the host’s Docker socket, triggering security red flags everywhere.
apiVersion: v1
kind: Pod
metadata:
# [...]
spec:
containers:
- env:
# [...]
volumeMounts:
- mountPath: /runner
name: runner
- mountPath: /runner/_work
name: work
- mountPath: /run
name: var-run
- mountPath: /var/run/secrets/kubernetes.io/serviceaccount
name: kube-api-access-97rpn
readOnly: true
# [...]
- args:
- dockerd
- --host=unix:///run/docker.sock
- --group=$(DOCKER_GROUP_GID)
So, we took matters into our own hands, manually eliminating this security risk. Little did we know, setting the container mode to Kubernetes would automatically handle this for us – a lesson learned the hard way. This mode also requires a workVolumeClaimTemplate to be configured and for security reasons should be set to ephemeral mode.
apiVersion: actions.summerwind.dev/v1alpha1
kind: RunnerDeployment
metadata:
name: first-runner
spec:
replicas: 1
template:
spec:
repository: m4s-b3n/playground
containerMode: kubernetes
workVolumeClaimTemplate:
storageClassName: default
accessModes:
- "ReadWriteOnce"
resources:
requests:
storage: "100Mi"
ephemeral: true
Step 3: Tackling RBAC Quandaries
Next up, RBAC (Role-Based Access Control) complexities emerged. The RBAC for the controller was decent, no need for meddling. But the runner’s RBAC? Not so much. We wanted control, so we decided to use our own service accounts.
Step 4: A Deep Dive into Custom CRDs
Our RBAC journey led us to custom CRDs (Custom Resource Definitions). The controller’s RBAC could be customized by assigning our self-created service account as part of the CRD. Simple enough.
---
apiVersion: v1
kind: ServiceAccount
metadata:
name: runner-service-account
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
name: runner-role
rules:
- apiGroups: [""]
resources: ["pods"]
verbs: ["get", "list", "create", "delete"]
- apiGroups: [""]
resources: ["pods/exec"]
verbs: ["get", "create"]
- apiGroups: [""]
resources: ["pods/log"]
verbs: ["get", "list", "watch"]
- apiGroups: ["batch"]
resources: ["jobs"]
verbs: ["get", "list", "create", "delete"]
- apiGroups: [""]
resources: ["secrets"]
verbs: ["get", "list", "create", "delete"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: runner-rolebinding
subjects:
- kind: ServiceAccount
name: runner-service-account
roleRef:
kind: Role
name: runner-role
apiGroup: rbac.authorization.k8s.io
---
apiVersion: actions.summerwind.dev/v1alpha1
kind: RunnerDeployment
metadata:
name: first-runner
spec:
replicas: 1
template:
spec:
repository: m4s-b3n/playground
containerMode: kubernetes
workVolumeClaimTemplate:
storageClassName: default
accessModes:
- "ReadWriteOnce"
resources:
requests:
storage: "100Mi"
ephemeral: true
serviceAccountName: runner-service-account
However, the runner’s pod creation process was a different beast.
Step 5: The Missing Puzzle Piece
Here’s where the documentation left us hanging: setting RBAC for the pod created to execute the Actions job. The projects issues became our virtual campfire, and after some crawling, we struck gold: GitHub Actions Runner Controller Issue #2992.
Step 6: PodTemplate to the Rescue
Enter the “PodTemplate.” We found a way to mount a Kubernetes PodTemplate into the runner, utilizing a service account we had created. This ingenious workaround allowed the runner to create pods using our service account, granting us the golden ticket to customize permissions as needed.
---
apiVersion: v1
kind: ServiceAccount
metadata:
name: runner-service-account
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
name: runner-role
rules:
- apiGroups: [""]
resources: ["pods"]
verbs: ["get", "list", "create", "delete"]
- apiGroups: [""]
resources: ["pods/exec"]
verbs: ["get", "create"]
- apiGroups: [""]
resources: ["pods/log"]
verbs: ["get", "list", "watch"]
- apiGroups: ["batch"]
resources: ["jobs"]
verbs: ["get", "list", "create", "delete"]
- apiGroups: [""]
resources: ["secrets"]
verbs: ["get", "list", "create", "delete"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: runner-rolebinding
subjects:
- kind: ServiceAccount
name: runner-service-account
roleRef:
kind: Role
name: runner-role
apiGroup: rbac.authorization.k8s.io
---
apiVersion: v1
kind: ServiceAccount
metadata:
name: job-service-account
---
apiVersion: v1
kind: ConfigMap
metadata:
name: pod-templates
data:
default.yaml: |
---
apiVersion: v1
kind: PodTemplate
metadata:
name: runner-pod-template
labels:
app: runner-pod-template
spec:
serviceAccountName: job-service-account
---
apiVersion: actions.summerwind.dev/v1alpha1
kind: RunnerDeployment
metadata:
name: first-runner
spec:
replicas: 1
template:
spec:
repository: m4s-b3n/playground
containerMode: kubernetes
workVolumeClaimTemplate:
storageClassName: default
accessModes:
- "ReadWriteOnce"
resources:
requests:
storage: "100Mi"
ephemeral: true
serviceAccountName: runner-service-account
volumes:
- name: pod-templates
configMap:
name: pod-templates
volumeMounts:
- name: pod-templates
mountPath: /home/runner/pod-templates
readOnly: true
In the end, our Terraform adventure wasn’t just about deployment – it was a journey through security revelations, RBAC complexities, and creative problem-solving.
Automation With Terraform
In the realm of modern software development, orchestrating seamless and reproducible workflows is paramount. While manually deploying applications through Kubernetes manifests and interacting with kubectl commands can be a quick way to get things up and running, professionals strive for more. The pursuit of a sustainable, scalable, and consistent deployment process has led us to harness the power of Terraform.
We required 4 providers…
terraform {
required_version = ">= 0.13"
required_providers {
azurerm = {
source = "hashicorp/azurerm"
version = "3.83.0"
}
kubernetes = {
source = "hashicorp/kubernetes"
version = "2.23.0"
}
helm = {
source = "hashicorp/helm"
version = "2.11.0"
}
kubectl = {
source = "gavinbunney/kubectl"
version = "1.14.0"
}
}
}
… and some variables …
variable "location" {
type = string
description = "Azure location for resources"
default = "westeurope"
}
variable "prefix" {
type = string
description = "Prefix for all resources"
default = "demo-features-arc"
}
variable "cluster_version" {
type = string
description = "The Kubernetes version for our clusters"
default = "1.27"
}
variable "cluster_node_size" {
type = string
description = "The Kubernetes node size for our clusters"
default = "standard_d2s_v5"
}
variable "k8s_namespace_cert_manager" {
type = string
description = "The Kubernetes namespace for deploying cert-manager"
default = "cert-manager"
}
variable "k8s_namespace_controller" {
type = string
description = "The Kubernetes namespace for deploying the actions runner contrtoller"
default = "demo-features-arc-controller"
}
variable "k8s_auth_secret_name" {
type = string
description = "The Kubernetes secret name for our GitHub App"
default = "github-auth-secret"
}
variable "github_app_id" {
type = string
description = "GitHub App ID"
sensitive = true
}
variable "github_app_install_id" {
type = string
description = "GitHub App Install ID"
sensitive = true
}
variable "github_app_private_key" {
type = string
description = "GitHub App Private Key"
sensitive = true
}
variable "arc_replicas" {
type = number
description = "Number of replicas for the Arc Controller"
default = 3
}
variable "runners" {
type = map(object({
repo_owner = string
repo_name = string
image = string
labels = list(string)
min_count = number
max_count = number
metrics = list(map(string))
}))
description = "List of GitHub repositories to add to the Arc Controller"
default = {
demo-features-arc-runner = {
repo_owner = "xpirit-training"
repo_name = "demo-features-arc"
labels = ["aks", "k8s"]
image = "summerwind/actions-runner:latest"
min_count = 2
max_count = 5
metrics = [
{
type = "PercentageRunnersBusy"
scaleUpThreshold = "0.75"
scaleDownThreshold = "0.25"
scaleUpFactor = "2"
scaleDownFactor = "0.5"
},
{
"type" = "TotalNumberOfQueuedAndInProgressWorkflowRuns"
"repository" = "xpirit-training/demo-features-arc"
"name" = "total"
}
]
}
}
}
variable "default_tags" {
type = map(string)
description = "Value for default tags"
default = {
owner = "xpirit-germany"
}
}
Note that we now use a GitHub App instead of a personal access token.
First, we created a resource group containing a virtual network and an AKS instance.
resource "azurerm_resource_group" "this" {
name = "rg-${var.prefix}"
location = var.location
tags = var.default_tags
}
module "network" {
source = "Azure/network/azurerm"
version = "5.3.0"
resource_group_name = azurerm_resource_group.this.name
use_for_each = true
address_space = "11.0.0.0/16"
subnet_prefixes = ["11.0.1.0/24"]
subnet_names = ["${var.prefix}-sn"]
depends_on = [
azurerm_resource_group.this
]
tags = var.default_tags
}
module "aks" {
source = "Azure/aks/azurerm"
version = "7.4.0"
prefix = var.prefix
cluster_name = "aks"
resource_group_name = azurerm_resource_group.this.name
kubernetes_version = var.cluster_version
orchestrator_version = var.cluster_version
automatic_channel_upgrade = "patch"
agents_size = var.cluster_node_size
agents_min_count = 1
agents_max_count = 3
agents_count = 1
os_disk_size_gb = 100
vnet_subnet_id = module.network.vnet_subnets[0]
rbac_aad = true
rbac_aad_managed = true
role_based_access_control_enabled = true
tags = var.default_tags
depends_on = [
module.network
]
}
To deploy into the cluster, we needed the helm, kubernetes, and kubectl provider to be set up correctly.
provider "kubernetes" {
host = module.aks.admin_host
username = module.aks.admin_username
password = module.aks.admin_password
client_certificate = base64decode(module.aks.admin_client_certificate)
client_key = base64decode(module.aks.admin_client_key)
cluster_ca_certificate = base64decode(module.aks.admin_cluster_ca_certificate)
}
provider "helm" {
burst_limit = 300
kubernetes {
host = module.aks.admin_host
username = module.aks.admin_username
password = module.aks.admin_password
client_certificate = base64decode(module.aks.admin_client_certificate)
client_key = base64decode(module.aks.admin_client_key)
cluster_ca_certificate = base64decode(module.aks.admin_cluster_ca_certificate)
}
}
provider "kubectl" {
host = module.aks.admin_host
username = module.aks.admin_username
password = module.aks.admin_password
client_certificate = base64decode(module.aks.admin_client_certificate)
client_key = base64decode(module.aks.admin_client_key)
cluster_ca_certificate = base64decode(module.aks.admin_cluster_ca_certificate)
load_config_file = false
apply_retry_count = 10
}
With the help of the Kubernetes and Helm providers, we were able to deploy the Kubernetes cert manager:
resource "kubernetes_namespace" "namespace_cert_manager" {
metadata {
name = var.k8s_namespace_cert_manager
}
depends_on = [module.aks]
}
resource "helm_release" "cert_manager" {
name = "cert-manager"
repository = "https://charts.jetstack.io"
chart = "cert-manager"
version = "v1.13.1"
namespace = var.k8s_namespace_cert_manager
#atomic = true
timeout = 600
set {
name = "installCRDs"
value = "true"
}
depends_on = [
kubernetes_namespace.namespace_cert_manager
]
}
Now, we had everything set up to deploy the controller and the runner using our new modules.
module "runner_controller" {
source = "infinite-automations/github-actions-runner-controller/helm"
version = "1.0.0"
namespace = var.k8s_namespace_controller
create_namespace = true
github_app_id = var.github_app_id
github_app_install_id = var.github_app_install_id
github_app_private_key = var.github_app_private_key
depends_on = [
module.aks,
helm_release.cert_manager
]
}
module "runner" {
source = "infinite-automations/github-actions-runner/kubectl"
version = "1.0.1"
for_each = var.runners
namespace = each.key
create_namespace = true
repo_owner = each.value.repo_owner
repo_name = each.value.repo_name
labels = each.value.labels
runner_image = each.value.image
min_count = each.value.min_count
max_count = each.value.max_count
metrics = each.value.metrics
depends_on = [
module.aks,
module.runner_controller
]
}
Assuming you already have your infrastructure up and running, these last few lines are everything to set up a working runner on Kubernetes.
Highlighting our commitment to community collaboration, we proudly share the Terraform modules we developed during this endeavor. These modules, now available on the Terraform Registry, empower others to replicate and extend our setup effortlessly.
Open-sourcing our work is not just a commitment but an invitation for the community to build, iterate, and innovate collectively.
Conclusion
As we wrap up this exploration, we reflect on the synergy between GitHub Actions Runner Controller, Kubernetes, and Terraform. The Innovation Day project not only unveiled the power of these tools but also exemplified how collaborative efforts can lead to innovative solutions. Dive into the world of GitHub Actions, Kubernetes, and Terraform with our comprehensive guide, and unlock a new realm of possibilities for your CI/CD workflows.
Links
GitHub Actions Runner Controller: https://registry.terraform.io/modules/infinite-automations/github-actions-runner-controller/helm/latest
GitHub Actions Runner: https://registry.terraform.io/modules/infinite-automations/github-actions-runner/kubectl/latest
About the author
writeabout.net
